Black-anodized aluminum parts (such as this decorative sheet-metal bracket) show a uniform, matte black finish that is integral to the metal.
Anodizing is an electrolytic passivation process that thickens aluminum’s natural oxide layer.
By dyeing or otherwise coloring this oxide, black anodizing produces a durable black coating.
The result combines the hardness and corrosion resistance of anodized alumina with the thermal and optical benefits of a black surface.
In practice, black anodizing is valued for its wear resistance, corrosion protection, and high emissivity (black anodized aluminum has an infrared emissivity around 0.85–0.90),
making it a popular finish in industries from aerospace to consumer electronics.
Definition of Anodizing and Special Case of Black Oxide Layers
Anodizing thickens aluminum’s oxide to protect against corrosion and wear. (The aluminum part itself is the anode in an acid bath, so the coating is truly part of the metal.)
Standard anodic films are transparent, but they can be dyed or otherwise colored. Black anodizing specifically means forming a black-colored oxide on aluminum.
It must be distinguished from black oxide on steel: black oxide (a conversion layer of iron oxide on steel) is unsuitable for aluminum.
By contrast, black anodizing produces an aluminum oxide (Al₂O₃) that is integral to the substrate.
Historically, anodizing was pioneered in the 1920s (for chromic and then sulfuric baths) to protect aircraft aluminum, and adding color soon followed.
Black anodizing gained prominence in mid-20th-century aerospace and military use, prized for creating a non-reflective, high-emissivity surface.
Today, it is an established industrial finish wherever a hard black surface is needed.
What is Black Anodizing?
Black anodizing is the process of creating a black oxide finish on aluminum by anodizing and coloration. The aluminum part is first sulfuric-acid anodized to form a porous oxide film.
In that porous film, a coloring agent is introduced (via dyeing or deposition) to impart a black color.
In most cases, this is done by post-dyeing: after anodizing, the part is immersed in a black dye bath (organic dyes or metal salts) which penetrates the pores and adsorbs onto the oxide.
Alternatively, some processes use electrolytic coloring, where a metal salt bath and applied current deposit a black compound (like nickel or cobalt salts) in the oxide.
A few high-alloy aluminum grades (especially thick hard anodize on 7000-series alloys) will color to a very dark gray “self-color” without dye, but true black is almost always achieved by dye or electrolytic means.
Black anodizing is typically done on aluminum alloys (5xxx, 6xxx, 7xxx series) that respond well to anodic oxide formation.
Magnesium and titanium can also be anodized and dyed black, but aluminum is most common.
Thicker “Type III” hard-anodized films (>25 μm) tend to produce deeper blacks, whereas thin “Type II” films (<25 μm) may yield a gray or purple tint if undersized.
(In fact, decorative Type II oxide films range 1.8–25 μm thick, while hardcoat Type III films exceed ~25 μm.)
The choice of alloy, oxide thickness, and dye type all influence how jet-black and fade-resistant the finish will be.
Uses of Black Anodizing
Black anodized aluminum is used wherever a hard, black surface is beneficial. Key applications include:
- Aerospace and optical components: Control of thermal radiation is critical in spacecraft and telescopes.
Black anodize is used on heat-sink surfaces, optical baffles, and avionics housings for its high emissivity and non-reflective finish. - Electronics and enclosures: Consumer devices and electronics (smartphone frames, laptop cases, instrument panels) often feature black anodized aluminum for both aesthetic appeal and scratch resistance.
- Automotive and architecture: Trim, decorative moldings, door hardware, and handrails sometimes use black anodize for a premium look that wears well in outdoor environments.
- Sports and industrial equipment: Bicycle parts, sporting goods, camera bodies, and hand tools use black anodized parts for durability and grip.
- Medical and laboratory instruments: Black-finished components in cameras, scopes, and lab equipment provide anti-glare optical surfaces.
- Weapons and defense: Firearm receivers and scopes on military rifles often use black anodizing (as opposed to paint) for a hard, stealthy finish.
In general, any application needing a wear-resistant, corrosion-resistant black coating on aluminum is a candidate for black anodizing.
The finish is favored when tight tolerances must be maintained (since anodize adds only a few microns), or when vacuum/clean-room compatibility is needed (anodize outgasses less than paints).
According to industry sources, black anodized aluminum is widely employed in automotive, aerospace, and electronics manufacturing due to its combination of durability and heat-dissipation properties.
Chemistry of Black Anodizing
The black color in anodized aluminum comes from dyes or pigments that fill the porous oxide.
The anodic oxide film on aluminum is highly porous, containing on the order of 10<sup>10</sup> pores per square inch.
These pores can be filled with coloring agents and then sealed. There are several chemistries:
- Organic dyes: Common black dyes are typically acid dyes (complex organic molecules) dissolved in water.
To achieve a deep black hue, relatively high concentration is needed (e.g. 6–10 g/L of dye, much higher than pastel colors).
The pores adsorb the dye molecules, giving color. Downsides: most organic dyes are UV-sensitive.
Under sunlight or fluorescent UV, the color will gradually fade or shift (often to a purple or bronze tone).
Good quality organic dyes offer modest lightfastness (many are rated 4–5 on a 1–8 scale), but even the best will degrade over years unless fully protected. - Inorganic/electrolytic coloring: Instead of dye, this uses metal salts that are driven into the film under an electric bias.
For example, sulfate or acetate salts of cobalt, nickel, copper, or bismuth can be used.
In an electrolytic black process, current causes metal or metal sulfides to precipitate inside the pores, creating a black or dark brown oxide (e.g. nickel sulfide or cobalt oxides).
These metal-derived blacks are much more lightfast than organic dyes – NASA studies found that anodized Al colored with metal-sulfide dyes showed only slight changes after simulated space-UV exposure.
Anodizers often refer to this as “integral” or two-step (anodize then electrolytic color). Because they form inorganic compounds, these blacks do not leach or fade easily. - Self-coloring by alloy: Very thick anodizing on certain high-strength alloys (with more copper or zinc content) can naturally produce dark colors.
For example, 6061 at ~50 μm thickness appears dark chocolate-grey, and 7075 or 2024 can blacken with specific treatments.
However, this effect is unpredictable and usually results in brownish tones. In practice, true jet-black nearly always comes from adding a colorant. - Sealing: After dyeing or coloring, the porous film is “sealed” by hydration.
The standard seal is boiling deionized water (which hydrates Al₂O₃ into boehmite, increasing the film volume), but for dyed films a 5–10 g/L nickel acetate solution at ~50–60°C is common.
Nickel acetate seals by precipitating Ni(OH)₂ in the pores. This not only locks in the dye but further enhances corrosion resistance.
Ni-acetate sealed anodize has excellent salt-spray durability – one report notes such coatings surviving ~3000 hours of ASTM B117 salt fog.
Note: dichromate seals (chromate treatments) used to be common for clear anodize,
but are banned in many regions for black anodize (and harmful to dye), so modern black anodize relies on water or nickel seals.
In summary, black anodizing chemistry revolves around creating the oxide film electrochemically and then using either organic dyes or inorganic (often electrolytic) coloring to achieve a durable black.
All pores must then be well-sealed to trap the color and improve resistance.
Process Parameters & Equipment
Electrolyte:
Black anodizing typically uses a sulfuric-acid bath. A common formulation is 15–20 wt% H₂SO₄ (about 150–200 g/L), often chilled to control temperature.
Some proprietary processes add small amounts of additives (e.g. 1% oxalic acid) to improve coating structure.
(For example, a sulfuric/oxalic mix can yield a denser film) The bath pH is strongly acidic, so all equipment must resist corrosion.
Current Density & Voltage:
For standard (Type II) anodizing, current densities around 1.2 A/dm² (12 A/ft²) are used. This produces a normal oxide growth rate.
For thicker “hard” anodize, higher current (2–3.6 A/dm², i.e. 20–36 A/ft²) is applied.
The voltage will vary (typically 12–20 V or more) to maintain the set current.
In practice, many anodizers use constant-current operation and time to achieve the desired film thickness
(the so-called “720 rule”: roughly 720 amp-min/ft² per mil of anodize, though exact times are calculated per job).
Temperature:
Room-temperature (~20–25°C) baths are used for decorative (Type II) anodizing.
Thicker hard-coatings require a cold bath (often 0–10°C) to control the heat generated by the high currents. Cooling coils or chillers are standard.
The bath is usually agitated or sparged with air to keep the temperature uniform and to flush oxygen bubbles from the surface.
Coating Thickness:
As a guideline, decorative Type II films are typically 1.8–25 μm thick.
For a rich, durable black dye, shops often aim for the upper end of that range (e.g. ~25 μm) to hide any slight color unevenness.
Hardcoat (Type III) films are thicker (generally >25 μm) and can be used if an extremely deep black or maximum wear resistance is needed.
Equipment and Racks:
Anodizing tanks are made of acid-resistant materials – usually steel lined with PVC or polypropylene.
Parts are hung in racks (commonly titanium or special anodized-aluminum fixtures) that serve as the cathode contact.
Good rack design and part fixturing are critical; insulated or coated rack areas can chip off and trap acid, so any flaking rack coatings are stripped.
A regulated DC power supply (rectifier) delivers the current, and the part itself is the anode.
Proper earthing and minimizing current bleeders are important to ensure uniform deposition.
In summary, black anodizing is run like standard sulfuric anodizing: an Al part in a 15–20% H₂SO₄ bath, anodized at about 1–3 A/dm² and controlled temperature.
With thick films and high currents, hard-coating setups (chilled tank, strong cooling) may be used.
Equipment must be maintained to very clean standards since contamination can ruin the color.
Surface Preparation & Pretreatment
Good surface preparation is crucial for consistent black anodizing.
The goals are to remove contaminants and achieve the desired surface finish before anodizing. Typical steps include:
- Mechanical cleaning (optional): Rough or poorly finished parts may be grit-blasted, sanded, or buffed to achieve a uniform matte or shiny base.
For instance, bead blasting yields a matte surface that masks minor imperfections, while fine sanding/polishing can create a brighter base finish. - Degreasing/Alkaline Clean: Parts are first cleaned in a caustic or alkaline detergent solution (often 60–70°C for a few minutes) to remove oils and dirt. Alkaline cleaning is usually followed by a thorough water rinse.
- Etching vs. Bright Dipping: After cleaning, parts are either etched or bright-dipped depending on the desired look.
-
- Etching: A dilute NaOH (caustic soda) solution (5–10%) is used to chemically “matte” the surface. This creates a uniform satin texture.
Etch times are short (seconds to a couple of minutes). A well-etched surface will give a slightly diffuse finish when anodized. - Bright Dip: Alternatively, a hot mixture of phosphoric and nitric acids (or proprietary brightening bath) can be applied briefly (often under 5 minutes) to smooth and shine the aluminum.
This produces a very lustrous, mirror-like finish after anodizing. Bright-dip is typically done at 90–100°C.
The choice of etch vs. bright-dip dramatically affects the final appearance of the black anodize: bright-dip yields a glossy black, while etch yields a matte black.
- Etching: A dilute NaOH (caustic soda) solution (5–10%) is used to chemically “matte” the surface. This creates a uniform satin texture.
- Desmutting: High-alloy or cast surfaces may require a “desmut” step after etching.
A dilute nitric acid dip removes any smut or residue (often a copper-rich film) left by the etch. This ensures the oxide that grows is uniform. - Racking: Parts are then racked in the anodizing fixtures. It’s important that the contact points (and any insulating rack coating) are sound.
Broken rack coatings can trap electrolyte under the part, causing pitting or arcing.
After anodizing, parts are usually washed immediately; lingering acid in crevices can cause localized discoloration.
(Finishing guides warn that “coated racks… can form pockets that entrap sulfuric acid,” so rack integrity is vital.)
By carefully combining these steps, an anodizer can produce either a dull or a mirror-black finish as needed.
In general, a thicker anodized film and high-quality seal are used when a true jet-black,
fade-resistant surface is required (since deeper pores hold more dye).
Performance Characteristics
Black anodized coatings exhibit the same high performance as other anodized layers, with some specifics related to the black color:
- Corrosion resistance: A properly sealed black anodize provides excellent protection against salt and humidity.
For example, the MIL-A-8625F specification (for Type II, Class 2 dyed anodize) requires 336 hours of 5% salt-spray (ASTM B117) with minimal corrosion.
In practice, bright black anodize that has been sealed in hot nickel acetate often vastly exceeds this – one source reports surviving on the order of 3000 hours before failure.
(Nickel-acetate seals are known to dramatically improve corrosion life of dyed anodize.) In contrast, an unsealed anodize or poor seal could rust quickly at cut edges.
In all cases, anodize does not “flame” like painting – failures are isolated pitting spots, not large chips. - Wear resistance: Hard black anodize (Type III) creates a very hard surface (around Rockwell 60C) that resists abrasion. Anodized finishes are commonly tested with the Taber Abraser.
The MIL specification sets an upper wear limit of about 1.5 mg weight loss per 1000 cycles for a copper-free alloy (and 3.5 mg/1000 cycles for high-Cu alloys).
In practice, a good hard-black coating on an Al 2000 or 7000 series can achieve wear losses on the order of 1–2 mg/1000 cycles, meaning very durable rubbing resistance.
(Even decorative Type II black anodize is harder than bare aluminum and will reduce galling and scratching.) - UV (light) stability: This is the main limitation. Organic black dyes are not UV-stable.
Under prolonged sunlight or strong UV, dyed blacks will fade, shift toward purple/bronze, or bleach out.
For example, medical equipment lamps with fluorescent UV can cause black anodized covers to “turn pink” over months.
The anodic layer itself won’t degrade, but the dye molecules slowly break down. Good sealing slows this, but cannot stop it.
As a rule, only inorganic black processes (metal-salt or electrolytic blacks) and some proprietary colorants provide long-term colorfastness.
Unless otherwise specified, one must assume any black anodize will gradually fade in outdoor/UV-heavy service.
(In a laboratory test, some customers found black oxide roofs on analyzers fading noticeably within a year under UV.)
In summary, black anodizing delivers the usual anodizing benefits (excellent corrosion and wear resistance) with the addition of black color.
Its corrosion protection is typically hundreds of hours of salt spray. It improves surface hardness dramatically (meeting MIL Taber wear limits).
The trade-off is color durability under UV – standard organic blacks are only suited to indoor or low-UV environments unless special dyes/seals are used.
Advantages & Limitations
Advantages:
Black anodize offers a unique combination of properties.
It produces a hard, thin, integral coating that wears and corrodes far better than painted black or black oxide on steel.
The finish is tough (enough for gears, pistons, and other wear parts) yet only a few microns thick, so it preserves dimensional tolerances.
It also provides excellent thermal-emissive behavior – NASA finds black-anodized Al has absorptance/emittance ~0.88 (finishing engineers report emissivity ~0.85–0.9 vs. ~0.83 for clear anodize).
Unlike paint or powder, anodized aluminum will not peel or crack under mechanical stress, and it is very thin and uniform.
Aesthetically, black anodize has a high-quality matte appearance prized on consumer products.
It also improves light absorption (useful in optics and solar) and electrical insulation (the alumina layer insulates while blacking out).
Limitations:
The downsides stem from the dye and process. All black anodize (especially organic-dyed) will eventually fade under UV and some chemicals.
Maintaining consistent color requires precise control of chemistry, time, and temperature – even slight variations can produce color streaks or shade differences.
It works only on susceptible aluminum alloys (5xxx/6xxx/7xxx); alloys with high silicon or copper can be hard to dye uniformly.
The coating also has limited “coverage” – it does not hide scratches or substrate defects like a thick black paint does.
In very high-temperature service (above a few hundred °C), the dye might scorch.
Finally, compared to plain clear anodizing, it is more expensive (due to extra baths/dyes) and slower (must dye and sometimes electrolytically color after the initial anodize).
In short, black anodizing pros include extreme hardness, corrosion resistance, high emissivity, and a premium look.
Its cons are sensitivity to UV (organic dye fade) and tighter process tolerances. With careful sealing and (if needed) inorganic electrolytic coloring, many limitations can be mitigated.
Comparative Finishes
Black oxide vs. black anodize:
Black oxide is a chemical conversion coating on steel (iron oxide, just a few nm thick) and cannot be applied to aluminum.
In contrast, black anodizing produces a thick aluminum-oxide layer that is integral to the part.
Consequently, black anodized aluminum is far more wear- and corrosion-resistant than any black oxide coating on steel.
(A steel part with black oxide will rust quickly once the film is breached, whereas anodized Al maintains a sealed ceramic barrier.)
Black oxide vs. Powder coating:
Powder-coated paint can produce a black finish on aluminum, but it differs in character.
Powder coatings are much thicker (50–150 μm typical) and sit on the surface, whereas anodizing is thin (5–30 μm) and part of the metal.
Powders (polyester, epoxy, etc.) fully hide the substrate and provide a smooth finish, but they are softer than aluminum and can chip or scratch off.
Anodize, by contrast, is harder than the metal and will not peel – it wears the metal instead of wearing off.
Powder coatings also tolerate a wider pH and weather range (no dye to fade), but they cannot achieve the same optical heat emissivity and may be too thick for tight tolerance parts.
In general, choose powder black for thick protection on sheet goods; choose black anodize for precise, wear-critical parts where thickness and hardness matter.
PVD/DLC coatings vs. Black oxide:
Physical Vapor Deposition (PVD) or Diamond-Like Carbon (DLC) can deposit extremely hard black layers on aluminum.
For example, black titanium nitride or carbon coatings give a deep black, high hardness finish. These require vacuum chambers and often an intermediate metal underlayer.
PVD blacks are harder yet than anodize and completely inert, but they are far more expensive and difficult (and typically used only for specialty optics or tooling).
They also form an add-on layer (which can delaminate under shock), unlike anodizing, which is built into the substrate.
When to choose black anodizing:
Black anodize is ideal when a hard, integral black coating is needed on aluminum.
For example, optical instrument housings, heatsink fins, engine parts, and high-end consumer electronics often use it.
If corrosion and wear resistance are primary, anodizing usually beats painting.
If color durability under sunlight is critical, one might instead use powder or specialized PVD blacks,
or specify inorganic (no-fade) anodic black processes.
As one comparison summary notes, anodized black is chosen for its “excellent wear resistance and unique metallic appearance” with a real oxide finish,
whereas powders or paints are chosen for complete coverage or outdoor longevity.
Conclusion & Best-Practice Recommendations
Black anodizing provides a versatile, high-performance black finish on aluminum, but it must be specified carefully.
Key criteria in deciding on black anodize include expected environment (indoor vs outdoor/UV),
required film thickness (Type II vs III), and mechanical stresses (abrasion, heat).
In a specification, one should clearly state: alloy type, anodize type (e.g. “sulfuric acid anodize, Type II, Class 2 dyed, per MIL-A-8625F”),
target coating thickness, sealing method (e.g. nickel acetate seal per ASTM B680), and required performance tests (salt-spray hours, UV/fade test if relevant).
For instance, a spec might call for 0.001–0.002″ (25–50 μm) black anodize on 6061-T6, sealed nickel acetate, per MIL-A-8625, with 168 h salt spray and ΔE≤3 after 1000 h Xenon-arc (AAMA 611) testing.
Best practices include using high-quality dyes or electrolytic colors with proven fade resistance,
controlling bath temperature and current for uniform growth, and avoiding long exposures to UV or harsh chemicals after anodizing.
Thoroughly rinse parts (avoiding rinse-drying errors) and apply seals correctly – remember that even a strong anodized coating can leak dyes if improperly sealed.
When durability is paramount, consider inorganic black processes: for example, one modern anodizer advertises using metal-salt (non-pigment) coloration that
“ensures exceptional UV resistance and no fading”, coupled with an advanced “AluGuard” seal that boosts corrosion and UV stability.
These emerging techniques point to the future of black anodizing: more resilient dyes and smarter seals.
In summary, black anodizing is a time-tested way to impart a hard, black surface on aluminum. It excels when durability, wear resistance, and heat management are needed.
By carefully specifying alloy, thickness, dye chemistry, and sealing, engineers can exploit its strengths while minimizing the weakness of color fade.
With proper application, black anodized finishes will serve effectively in demanding roles for years to come.
Ongoing innovations in chemistry and sealing promise even greater stability in the future.
LangHe is the perfect choice for your manufacturing needs if you need high-quality black anodizing services.
FAQs
What materials can be black anodized?
Primarily, aluminum and its alloys are black anodized.
Some magnesium and titanium alloys can undergo similar anodic treatments, but true anodizing processes are mainly optimized for aluminum.
Is black anodizing just painting the surface?
No. Black anodizing is not a paint or coating.
It modifies the metal surface through controlled oxidation, creating a hard, integrated finish that will not peel, chip, or flake like paints.
How durable is black anodizing?
Black anodized surfaces are highly durable and have excellent resistance to abrasion, corrosion, and wear. Properly sealed black anodized parts can pass ASTM B117 salt spray tests for hundreds of hours.
Will black anodizing fade over time?
Yes, over long-term UV exposure, some black dyes can fade. However, high-quality black anodizing with UV-stable dyes and proper sealing techniques minimizes fading significantly.
How thick is a black anodized layer?
Typical black anodizing thickness ranges from 10 to 25 microns (0.0004 to 0.0010 inches), depending on the process type (Type II or Type III anodizing) and application requirements.
Is black anodizing conductive?
Anodized layers, including black ones, are electrically insulating. If electrical conductivity is needed, masked areas must be left unanodized, or selective stripping must be performed.
What is the cost of black anodizing?
Costs depend on part size, quantity, anodizing thickness, dye quality, and any additional surface treatments (like sealing or masking).
Generally, black anodizing is more expensive than clear anodizing due to the dyeing step.
